Trek Madone SL 6 Gen 8 - White Prismatic

The Madone SL 6 Gen 8 is a lightweight aero racing bike that makes Elite racing technology affordable. It offers similar aerodynamic advantages as the higher-priced Madone SLR Gen 8 but is based on a more affordable layup of 500 Series OCLV Carbon and a two-piece cockpit with internal cable routing. Built for racing, its geometry ensures high comfort on climbing sections and allows for aggressive attacks. The electronic Shimano 105 Di2 group keeps the price low and the shifting performance high. The carbon wheels contribute to the bike's super lightweight performance.

• The revolutionary Full System Foil tube profiles ensure an extremely fast Look and give the entire bike unprecedented aerodynamic efficiency.
• The frame made of more affordable 500 Series OCLV Carbon and the new tube profiles save important weight for superior climbing performance.
• For efficient climbs and confident descents, the carbon wheels reduce weight and increase performance.
• Thanks to Shimano's 105 Di2 group with high-end technology, you benefit from crisp and clean gear changes.
• The lightweight, race-focused IsoFlow comfort technology helps you pedal longer and stronger.
• As an absolute novelty in the history of Trek's performance racing bikes, this bike comes completely tubeless.



Equipment:
Frame: 500 Series OCLV Carbon, Full System Foil tube profiles, IsoFlow seat tube, RCS Headset System, electronic or mechanical shifting possible, removable aero chain guide, T47 bottom bracket, Flat Mount disc brake mount, UDH, 142 x 12 mm thru axle
Fork: Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Front Wheel: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 100 x 12 mm thru axle
Rear Wheel: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 11/12-speed freehub from Shimano, 142 x 12 mm thru axle
Front/Rear Quick Release: Bontrager Switch chamfered thru axle, removable lever
Rim: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, 100x12mm thru axle
Tire: Bontrager R3 Hard-Case Lite, Tubeless-Ready, Aramid bead core, 170 TPI, 700 x 28 mm
Tire Spare Part: Bontrager TLR Sealant, 177 ml
Rim Tape: Bontrager TLR
Max. Tire Size: 32 mm (as measured, exact specifications can be found in the manual)
Shift Lever: Shimano 105 R7170, 12-speed
Front Derailleur: Shimano 105 R7150 Di2, braze-on, Down-Swing
Rear Derailleur: Shimano 105 R7150 Di2, 36 T on largest cog
Crank: Shimano 105 R7100, 50/34 T, 165 mm crank arm length (XS, S)
Crank: Shimano 105 R7100, 50/34 T, 170 mm crank arm length (M)
Crank: Shimano 105 R7100, 50/34 T, 172.5 mm crank arm length (ML, L)
Crank: Shimano 105 R7100, 50/34 T, 175 mm crank arm length (XL)
Bottom Bracket: Praxis, T47, threaded, internally mounted
Cassette:  Shimano 105 7101, 11-34 T, 12-speed
Chain: Shimano SLX M7100, 12-speed
Max. Chainring Size: 1x: 54 T, 2x: 56/43
Saddle: Bontrager Aeolus Comp, steel rails, 155 mm width (XS, S)
Saddle: Bontrager Aeolus Comp, steel rails, 145 mm width (M, ML, L, XL)
Seatpost: Madone, Aero seatpost made of carbon, 0 mm offset, short length (XS, S, M)
Seatpost: Madone, Aero seatpost made of carbon, 0 mm offset, long length (ML, L, XL)
Handlebar: Bontrager Comp, aluminum, 31.8 mm clamp diameter, 80 mm reach, 121 mm drop, 36 cm top handlebar width, 40 cm bottom handlebar width (XS)
Handlebar: Bontrager Comp, aluminum, 31.8 mm clamp diameter, 80 mm reach, 121 mm drop, 38 cm top handlebar width, 42 cm bottom handlebar width (S, M)
Handlebar: Bontrager Comp, aluminum, 31.8 mm clamp diameter, 80 mm reach, 121 mm drop, 40 cm top handlebar width, 44 cm bottom handlebar width (ML, L)
Handlebar: Bontrager Comp, aluminum, 31.8 mm clamp diameter, 80 mm reach, 121 mm drop, 42 cm top handlebar width, 46 cm bottom handlebar width (XL)
Stem: Trek RCS Pro, -7 degrees, 80 mm length (XS)
Stem: Trek RCS Pro, -7 degrees, 90 mm length (S, M)
Stem: Trek RCS Pro, -7 degrees, 100 mm length (ML, L)
Stem: Trek RCS Pro, -7 degrees, 110 mm length (XL)
Brake Disc: Shimano RT70, Center Lock disc mount, 160 mm
Brake Disc Diameter: Max. brake disc diameter: 180 mm front, 160 mm rear
Weight: ML - 8.16 kg / 17.99 lbs (with TLR tire sealant, without tubes)
Max. Weight: This bike has a maximum weight limit (bike, rider, and cargo) of 125 kg.

* Specification may vary in details in exceptional cases due to manufacturer.
