Focus ATLAS 8.7 - Melon

KNOWS NO LIMITS

COMFORTABLE AND AGILE ON ALL ROUTES
This lightweight carbon bike weighs only 9.6 kg and is designed for your fast gravel adventures. The combination of a longer reach and short stem gives the bike an exceptionally smooth ride. The front is relatively high, providing you with confidence during descents. To keep our gravel bike nimble, the frame has particularly short chainstays. This agility will delight all riders who love to challenge each other, no matter the terrain. To ensure you perfectly handle demanding gravel routes with this fast bike, you can individually adjust the handlebar position to your needs. We offer stems in six lengths from 70 to 120 mm, and the handlebar height can be adjusted via special two-piece spacers.

MULTIPLE OPTIONS FOR TRANSPORTING LUGGAGE
The ATLAS 8.7 frame offers numerous attachment points for comfortably transporting your bags. Handlebar, saddle, and frame bags can be easily attached. The top tube bag is included with our ATLAS 8.7. Here you can store essential tools or snacks for a quick bite during your ride. For bottle cages, the frame offers three additional mounting points. One can be mounted on the seat tube, and two others on the down tube—one above and one below. Additionally, the three screws on both the left and right sides of the fork allow you to attach more luggage. Here you can mount carriers for additional bags or bottle cages. The ATLAS 8.7 is designed for a maximum system weight (bike, rider, and equipment) of 120 kg.

DESIGNED FOR FAST GRAVEL ADVENTURES
The ATLAS 8.7 features fast-rolling, tubeless-ready 45 mm WTB Riddler tires and a Shimano GRX600 2x11 groupset with special gravel gearing suitable for bikepacking adventures. The wide handlebar with flare provides increased safety and comfort. The C.I.S. (Cockpit Integration Solution) technology ensures a tidy cockpit with no cables in the way when attaching a handlebar bag. Whether facing bad weather conditions or challenging terrain, suffering on steep climbs or mastering truly long distances—the ATLAS 8.7 supports you on all your rides, even to the ends of the earth.

Specifications:
Brake: 160 mm
Size (Frame): XS - 48cm, S - 51cm, M - 54cm, L - 57cm, XL - 60cm
Drivetrain: Chain
Groupset: 24-speed Shimano GRX 620
Wheelset: DT Swiss G1800, 24-622, 12x110 mm / 12x148 mm, 25 mm height
Permissible total weight: 120 kg
Frame: Carbon, disc, C.I.S. integration, press fit BB86, 148x12 mm thru-axle, flat mount 160/160 mm, internal cable routing, Toptube Bag
Fork: Carbon, disc, 110x12 mm thru axle, flat mount 160/160 mm, internal brake cable routing, multiple mounting points
Handlebar: FOCUS JD RA85, 31.8 mm, drop: 116 mm, reach: 74 mm, flare: 10°
Saddle: Prologo Akero
Seat post: Lee Chi SP-926, Carbon, 27.2 mm, set-back: 0 mm
Stem: FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium, with Garmin / Wahoo mount
Brake: Shimano CN-LG50, Shimano CN-LG50
Crankset: Shimano RS520
Cassette: Shimano 105 R7100, 12-speed
Handlebar tape: FOCUS Bartape SL
Rear derailleur: Shimano GRX RD-RX820, 12-speed
Tires: WTB Riddler, 700 x 45C, folding
Shift/brake levers: Shimano GRX ST-RX620, 12-speed
Chain: Shimano 105 CN-M6100, 12-speed
Front derailleur: Shimano GRX FD-RX820

* Specification may vary in details in exceptional cases due to manufacturer conditions.
